R542 Compression Load Cell

Mainly used in grinding and polishing machine sensors with high precision and good lateral resistance.

Material:
Features:
Size:
Quantity:
  • R542
  • Right
  • Compression
  • IP66
Product Description



Dimensions

T912 installation drawingsR542 installation size jpg






Parameter


Specifications


Technical index / Technique


Capacity

5,10,20,50 kg

Zero Balance

2.0 ± 10% mV / V

Non-linearity

± 3% mV / V

Temp. Effect on sensitivity (TKc)

0.2% F.S. / 10 ℃

Temp. Effect on zero balance (TKo)

0.2% F.S. / 10 ℃

Input Resistance

385 ± 20 Ω

Output Resistance

350 ± 10 Ω

Insulating Resistance

≥5000 MΩ / 100VDC

Excitation Voltage

5 V

Max. Excitation Voltage

15 V

Compensation Range

-10 ~ 60 ℃

Service Temperature Range

-20 ~ 80 ℃

Limit load (EL)

150% F.S.

Breaking load (Ed)

200% F.S.

Cable Size

φ3 × 2000 mm

Weight (G), approx.

0.1 kg

Material (Measuring element)

Stainless steel

IP Class

IP66





Features & Applications


Mainly used in grinding and polishing machine sensors, the characteristics of the sensor load can rotate the force measurement, high precision and good lateral resistance;

Good stability, strong bending moment, low height, small deformation and easy installation.



Force Mode


R542 Force mode





Wiring Code

Wiring regulations





Download   R542.pdf
