R581 Weighing Load Cell

It is widely used in weighing systems such as construction machinery and garbage truck weighing.

Material:
definition:
Quantity:
  • R581
  • Right
  • Weighing
  • 20kN ~
  • IP68
Product Description



Dimensions


R581 图纸





Parameters


Specifications

Technique

Capacity

550, 880 kg

Sensitivity

2.0 ± 0.1% mV / V

Zero Balance

± 5% F.S.

Non-linearity

0.02% F.S.

Hysteresis Error

0.02% F.S.

Repetition

0.0% F.S.

Creep (30 min)

0.05% F.S.

Temp. Effect on sensitivity (TKc)

0.05% F.S. / 10 ℃

Temp. Effect on zero balance (TKo)

0.05% F.S. / 10 ℃

Input Resistance

380 ± 20 Ω

Output Resistance

350 ± 5 Ω

Insulating Resistance

≥5000 MΩ / 100VDC

Excitation Voltage

5 ~ 12 V

Max. Excitation Voltage

15 V

Compensation Range

-10 ~ 60 ℃

Service Temperature Range

-20 ~ 80 ℃

Limit load (E L)

150% F.S.

Breaking load (E d)

200% F.S.

Cable size

φ8 × 2000 mm

IP Class

IP67






Features and Applications


Stainless steel material, strong stability

Suitable for various environments, IP 68

Stable structure and strong lateral resistance, mainly suitable for weighing systems such as construction machinery and garbage trucks





Load Direction


R581 受力方式





Wiring Code


Wiring regulations





Download  R581 样本.pdf
