You are here: Home » Force Sensors » Tension / Clip Load Cells » Surface Tension » T205 Tension Load Cell
  • T205
  • Right
  • Tension
  • 100N~1000N
  • IP65
Product Description


Dimension


T205-2





Parameters


Specifications

Technique

Capacity

10,20,50 kg

Sensitivity

1.0 ± 20% mV / V

Zero Balance

± 0.05 mV / V

Non-linearity

0.1% F.S.

Hysteresis Error

0.1% F.S.

Repetition

0.05% F.S.

Creep (30 min)

0.05% F.S.

Temp. Effect on sensitivity (TKc)

0.05% F.S. / 10 ℃

Temp. Effect on zero balance (TKo)

0.05% F.S. / 10 ℃

Input Resistance

350 ± 10 Ω

Output Resistance

350 ± 10 Ω

Insulating Resistance

≥5000MΩ / 100VDC

Excitation Voltage

5 ~ 12 V

Max. Excitation Voltage

15 V

Compensation Range

-10 ~ 60 ℃

Service Temperature Range

-20 ~ 80 ℃

Limit load (E L)

150% F.S.

Breaking load (E d)

200% F.S.

Cable size

φ5 × 4000 mm

Material (Measuring element)

Stainless steel

IP Class

IP65






Features and Applications


Tension measuring sensor

Compact structure, easy to install

Protection level: IP 67

Super anti-overload capability

Various ranges and sizes can be customized




Load Direction


T205-3




Wiring Code


Wiring regulations



Download    T205 .pdf
