T721C
Right
Weighing
20kN ~
IP65, IP67
Specifications
| Specifications | Technique |
| Capacity | 30,50kg |
| Rated output | 2.0±10%mV/V |
| Zero balance | ±3%mV/V |
| Non-linearity | 0.02%F.S. |
| Hysteresis | 0.02%F.S. |
| Repeatability | 0.20%F.S. |
| Creep(30min) | 0.10%F.S |
| Temp.effect on output | 0.0175%F.S./10℃ |
| Temp.effect on zero | 0.02%F.S./10℃ |
| Input impedance | 400±20Ω |
| Output impedance | 350±10Ω |
| Insulation | ≥5000MΩ/100VDC |
| Recommended excitation | 5~12V |
| Maximum excitation | 15V |
| Compensated temp range | -10-40℃ |
| Operating temperature range | -35~65℃ |
| Safe load limit | 120%F.S. |
| Ultimate overload | 200%F.S. |
| lP class | IP65(Customizable IP67) |
| Cable size | φ5.3-2m |
FAQ
What are your terms of packing?
Generally, we pack our goods in bulks or wooden box, suitable for shipping container.
What is your terms of payment?
T / T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
What are your terms of delivery?
EXW, FOB, CFR, CIF.
How about your delivery time?
Generally, it will take 10 to 15 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Can you produce according to the samples?
Yes, we can produce by your samples or technical drawings.
