R135 Tooling Fixture Test Sensor

Used for upper and lower molds, tooling fixtures, etc. where parallelism needs to be tested;Patented products, counterfeiting will be investigated

Material:
Features:
Quantity:
  • R135
  • Right
  • customization
  • 100N~1000N
  • IP66
Product Description



Dimension


R135-2





Parameter


Specifications

Technique

Capacity

50,100,200,500 N

Sensitivity

0.5 ± 20% mV / V

Zero Balance

± 2% F.S.

Non-linearity

0.05% F.S.

Hysteresis Error

0.05% F.S.

Temp. Effect on sensitivity (TKc)

0.05% F.S. / 10 ℃

Temp. Effect on zero balance (TKo)

0.05% F.S. / 10 ℃

Input Resistance

350 ± 10 Ω

Output Resistance

350 ± 10 Ω

Insulating Resistance

≥5000 MΩ / 100VDC

Excitation Voltage

5 V

Max. Excitation Voltage

10 V

Compensation Range

-10 ~ 60 ℃

Service Temperature Range

-20 ~ 80 ℃

Limit load (E L)

150% F.S.

Breaking load (E d)

300% F.S.

Cable size

φ3 × 3000 mm

IP Class

IP66






Features and Applications


stainless steel material

High precision, stable and reliable measurement

Used for upper and lower molds, tooling fixtures, etc. where parallelism needs to be tested

Various specifications can be customized

Patented products, counterfeiting will be investigated




Load Direction


r135-3





Wiring Code


Wiring regulations




Download   R135.pdf
